Vantec TSX-300 LED-Display ATX Case

Description

LED iCON Display — At-a-Glance System Feedback

The TSX-300’s most distinctive feature is its front-mounted LED iCON display, which provides visual status indicators directly from the front panel — a practical touch that sets it apart from plain chassis designs. Beyond aesthetics, the front panel delivers a solid connectivity lineup including eSATA for fast external storage access, audio in/out jacks, and a FireWire (IEEE 1394) port alongside two USB ports — giving this case a broad range of peripheral connections accessible without reaching around to the back of the machine.

Generous Storage Capacity with Screw-Less Installation

Internal storage flexibility is one of the TSX-300’s stronger suits. It accommodates up to four 5.25″ optical or accessory bays, one exposed 3.5″ bay, and four hidden 3.5″ drive bays with side-removable trays — enough to support both an optical drive setup and a sizeable HDD array without compromise. The screw-less tool-free design extends to PCI, 3.5″, and 5.25″ bays, making drive installation and swaps quick and hassle-free without needing a screwdriver.

Built with Thermal Headroom in Mind

The TSX-300 was designed with practical thermal management as a priority. Two 120mm silent fans — one front intake, one rear exhaust — provide baseline airflow, with support for up to three fans total if additional cooling is needed. A dedicated CPU air guide on the side panel channels fresh air directly toward the processor, while a separate VGA card cooling vent helps manage GPU thermals. Water cooling pipe holes are also present for builders who want to run custom loop tubing through the chassis. The case offers large internal clearance for high-wattage power supplies and longer graphics cards.

⚠️ Buyer Tip: The TSX-300 is a legacy-era chassis. The front I/O includes USB 2.0 ports only — there is no USB 3.0 or USB-C on the front panel. The eSATA and IEEE 1394 (FireWire) ports, while useful in their time, are rarely used by modern peripherals. If fast front-panel USB access is important to your workflow, this case may not be the best fit. It remains a solid option for budget office builds, secondary systems, or HDD-heavy storage rigs where modern I/O is not a priority.

Key Highlights

• Form Factor: Midi Tower (ATX)
• Front Display: LED iCON Status Display
• Drive Bays: 4× 5.25″, 1× 3.5″ (exposed), 4× 3.5″ (hidden, side-removable)
• Pre-Installed Fans: 1× 120mm Front, 1× 120mm Rear
• Max Fan Support: Up to 3× 120mm
• Side Panel: CPU Air Guide + VGA Cooling Vent
• Water Cooling: Pipe holes included
• Front I/O: 2× USB 2.0, eSATA, IEEE 1394 (FireWire), Audio In/Out
• Installation: Screw-less tool-free (PCI, 3.5″, 5.25″ bays)
• Dimensions: 200 × 410 × 490mm (W × H × D)
• Colour: Black
• PSU: Not included (standard ATX)
