Gigabyte Z590I Vision D (LGA1200)

Description

Flagship Features. Tiny Footprint.

The VISION Series motherboards are built for creator PCs, with reliable performance, impressive connectivity, and ultra-fast storage for creators dealing with heavy design workloads like video editing and 3D rendering. It’s the perfect fit for DIY creators building their own ideal compact machine.

Dual Thunderbolt 4 — 40Gb/s

Thunderbolt 4 delivers 40Gb/s high-bandwidth speeds for data transfer, video signal, and power charging, with USB4 specification compliance for maximum flexibility connecting accessories — all through a single USB Type-C cable. Having dual Thunderbolt 4 on a Mini-ITX board is extraordinarily rare.

PCIe 4.0 & Dual M.2

Dual M.2 connectors — one PCIe 4.0 on the primary slot for Rocket Lake CPUs — deliver up to 7x faster data transfer than SATA SSDs. Combined with PCIe 4.0 x16 support, storage and GPU performance is thoroughly modern despite the compact form factor.

2.5GbE & Wi-Fi 6

2.5 GbE LAN running at 2.5 times the speed of standard Gigabit networking is complemented by Wi-Fi 6 wireless at up to 2.4 Gb/s — keeping this creator board connected at speed in any environment.

⚠️ Important: PCIe 4.0 M.2 operation requires an 11th Gen (Rocket Lake) LGA1200 CPU. With 10th Gen (Comet Lake), the primary M.2 slot runs at PCIe 3.0 speeds.

Key Highlights:

• Intel Z590 Chipset | LGA1200 | Mini-ITX | Supports 10th & 11th Gen Intel Core
• 2x DDR4 DIMM Slots | Up to 64GB | DDR4-3200
• 1x PCIe 4.0 x16 GPU Slot | 2x M.2 Slots (PCIe 4.0 primary)
• 2x Thunderbolt 4 (USB Type-C) | 40Gb/s | USB4 Compliant
• Wi-Fi 6 (802.11ax) | Bluetooth 5.1 | Dual 2.5Gb Intel Ethernet
• Realtek ALC4080 HD Audio | DisplayPort In (VisionLINK)
• Smart Fan 6 | M.2 Thermal Guard | Q-Flash Plus
• Dimensions: 170 × 170mm
